XC308-Digital Multimeters

• 0.05% basic DC accuracy
• 40 000-count resolution
• Measures frequency, capacitance and temperature
• True RMS AC/DC voltage and current measurements
• Diode check and continuity test
• Backlit LCD readout with analog bar graph
• 1000 V input protection on all ranges
• 4-20 mA process loop measurements with % readout
• Data hold, Max/Min recording mode
• Peak capture mode
• IP67 dust and waterproof
• EN61010-1 Cat. IV 600 V, Cat. III 1000 V safety rating
• Includes test leads and 9 V battery

Specifications

• Voltage Readings: AC/DC
• Current Readings: AC/DC

Additional Specifications

• AC/DC Voltage Range: 1000 V
• Voltage Accuracy: AC ±1.0%, DC ±0.05%
• AC/DC Current Range: 10 A
• Current Accuracy: AC ±1.5%, DC ±1.0%
• Resistance Range: AC ±1.5%, DC ±1.0%
• Resistance Accuracy: ±0.3%
• Frequency Accuracy: ±0.1%
• Capacitance Range: 40 mF
