NIS682 - AFRM14 Intermediate Air Filter & Regulator Combination

NIS682 - AFRM14 Intermediate Air Filter & Regulator Combination

by TG Store
SKU: NIS682
$74.38 - $74.38
$74.38
$74.38 - $74.38
$74.38

Specifications:

  • Connection Size: 1/4" NPT
  • Operating Pressure: 145 PSI

Description

  • Air filter and regulator combined in one unit
  • Air filter is designed to eliminate dust, water, and other impurities from reaching air tool, extending tool life
  • Air regulator governs air flow to desired PSI air pressure
  • Regulators uses a Non Raising "Press to Lock" adjusting knob for locking at any set pressure
  • Regulators work on a diaphragm-operated relieving-type mechanism with pressure compensated by balanced poppet
  • Bowl Filter Size: 9 ml (0.3 oz.)
  • Width: 1.57"
  • Max. Air Flow: 20 CFM (550 LPM)
  • Pressure Gauge Port Size: 1/8"
  • Temperature Range: 0°C to 60°C (32°F to 140°F)
  • Height: 6.69"
    •
