ML706-Heavy-Duty Kingpinless Caster

• 1/2" zerk axle and lock nut
• 5/16" diameter thrust raceway; 5/16" diameter kingpin raceway
• Raceway protected from dust and dirt
• Corrosion resistant bright zinc finish
• Brake type: Total locking ; Excellent for:
• Abusive conditions
• Tow lines
• Industrial platform trucks
• Most hardworking industrial functions
• Economical handling of heavy loads where severe abuse is present

Specifications

• Wheel Diameter: 8" (203.2 mm)
• Capacity: 1760 lbs. (798.32 kg.)
• Wheel Material: Thermoplastic Polyurethane
• Caster Type: Swivel
• Frame Material: Steel
• Tread Width: 2" (50.8 mm)
• Bolt Hole Spacing: 2-7/16" x 5-1/4" (62 mm x 133 mm) to 3-3/8" x 4-15/16" (86 mm x 125 mm)
• Bolt Hole Size: 1/2" (12.7 mm)
• Plate Size: 4-1/2" x 6-1/4" (114 mm x 159 mm)

Additional Specifications

• Bearing Type: Roller
• Swivel Radius: 6.5"
• Overall Height: 9.5"
