ML020-Caster

• Heavy-duty double swivel raceway
• Grey thermoplastic rubber is non-marking and includes synthetic tread guards to protect roller bearings
• Durable zinc-plated pressed steel assembly for durability

Specifications

• Wheel Diameter: 3-1/8" (79.5 mm)
• Capacity: 130 lbs. (59 kg.)
• Wheel Material: Thermoplastic Rubber
• Caster Type: Rigid
• Frame Material: Steel
• Tread Width: 1-1/4" (31.75 mm)
• Bolt Hole Spacing: 2-3/4" x 1-3/4" (70 mm x 44 mm)
• Bolt Hole Size: 5/16" (7.93 mm)
• Plate Size: 2-1/2" x 3-1/2" (64 mm x 89 mm)

Additional Specifications

• Bearing Type: Ball
• Overall Height: 4.25"
• Brake Type: Top Locking
