ID650 - Professional Solar Clamp Meter

Specifications:

• Voltage Readings: AC/DC
• Current Readings: AC/DC

Description

• Measures AC/DC current and voltage, resistance, capacitance, frequency, and contact temperature
• High-resolution 9,999-count backlit LCD display
• Dual display allows simultaneous viewing of voltage and current measurements
• True RMS voltage and current for accurate measurements
• Expandable AC current measurement up to 3000A with the flexible current probe (R5065, sold separately)
• Slim jaw design for easy access to cables in crowded combiner boxes, with the capacity to clamp around multiple cables
• Ergonomically designed for a comfortable grip and can be used with protective gloves
• DC power measurement capability with kVA readings
• IP65-rated for reliable performance in dusty or damp outdoor environments, ideal for solar and wind power applications
• Audible and visual polarity indicator to prevent accidental miswiring
• Low Pass Filter (LPF) and inrush measurement capabilities for precise motor and HVAC testing
• Min, Max, Average, Peak capturing and display hold
• Diode test and continuity check functions
• Low battery and over-range indicators
• Cat. III 1500V, Cat. IV 600V safety rating
