ID556 - Differential Pressure Manometer

ID556 - Differential Pressure Manometer

by TG Store
SKU: ID556
$324.03 - $324.03
$324.03
$324.03 - $324.03
$324.03

Specifications:

  • Display: Digital

Description

  • Differential, absolute, and static pressure measurements
  • 0.01 WC max resolution for static pressure measurement
  • Measurement range of +/- 60 WC
  • Up to 200 hours of operation on a single 9V battery
  • Field-adjustable zeroing to ambient pressure for highly accurate low pressure readings
  • Two 5/16 adapters for reading pressures of inlets and outlets
  • Gas and static pressure plus differential
  • Measure duct pressures to balance air flow
  • Resolution down to 0.01"WC for static pressure measurement -60 to 60.0"WC range
  • Includes: SDMN5 Dual Port Manometer; (2) 3/16 Tubes with Brass Fittings; (2) 3/16 to 5/16 Tube Adapters - RMA316; 9V Battery (Installed); Operator's Manual
  • Operating Environment: 32 to 122°F (0 to 50°C)
  • Battery Life: 200 Hours
  • Auto-Off Power: 15 Minutes
  • Pressure Ports: Tube Connectors for 5mm (~3/16") I.D. Flexible Tubing
  • Units of Measure: inWC, mmWC, mbar, PSI
  • Resolution: 0.01 inchWC (0.1mmWC, 0.01mBar)
  • Accuracy: inWC: ±0.02 on 0.00 to ±2.00 (±1.5% FS on 2.00 to ±60.0), mmWC: ±0.5 on 0.00 to ±51.0 (±1.5% FS on 51.0 to ±1500), mbar: ±0.05 on 0.00 to ±5.00 (±1.5% FS on 5.00 to ±150.0), psi: ±0.001 on 0.000 to ±0.07 (±1.5% FS on 0.07 to ±2.000)
  • Dimensions: 7.06" x 2.38" x 1.19" (180 x 60 x 30 mm)
    •
