ID545 - Brushless Refrigerant Recovery Unit

Name: ID545 - Brushless Refrigerant Recovery Unit
Brand: TG Store
SKU: ID545
Price: 1462.12 CAD
Availability: InStock

by TG Store

SKU: ID545

$1,462.12 - $1,462.12

$1,462.12

$1,462.12 - $1,462.12

$1,462.12

Specifications:

Motor: 1 HP

Description

Compact and lightweight unit
Easy to store and carry at only 20.3 lbs. (9.2 kg)
Brushless DC motor technology
Soft and easy starting
Fast recovery using twin cylinder and large condenser
Easy to use one key operation
Purge function to prevent mixing of various refrigerants
Oil-Free compressor is suitable for all common refrigerants
CSA safety certification - Full-tank, overload and high pressure protection
A2L compatible

Applications: HVAC/R Systems, Automotive Industry, Leak Detection, Refrigeration, Industrial Processes

Refrigerant Type: Category III: R-12, R-134a, R-1234YF, R-401C, R-500, Category IV: R-22, R-401A, R-401B, R-402B, R-407C, R-407D, R-408A, R-409A, R-454B, R-502, R-509, Category V: R-32, R-402A, R-404A, R-407A, R-407B, R-410A, R-454B, R-507

Recovery Rate: Direct Vapor: R-410A: 0.54 lbs/min (0.25 kg/min), R-22: 0.58 lbs/min (0.27 kg/min), R-134a: 0.47 lbs/min (0.21 kg/min), Direct Liquid: R-410A: 12 lbs/min (5.5 kg/min), R-22: 9 lbs/min (4.1 kg/min), R-134a: 8 lbs/min (3.6 kg/min), Push / Pull Liquid: R-410A: 17 lbs/min (7.8 kg/min), R-22: 15.8 lbs/min (7.2 kg/min), R-134a: 15 lbs/min (6.8 kg/min)

Motor Speed: 3000 RPM

Compressor: Oil-Less, Air-Cooled, Piston

High Pressure Protection: 38.5 bar

Power: 115 V/60 Hz

Dimensions: 12.2" x 9.4" x 9.6" (310 x 239 x 244 mm)

Weight: 20.3 lbs. (9.2 kg)
