ID361-Thickness Gauge with 5-Step Calibration Block

• Internal memory capable of storing up to 300 readings with user alarm thickness limits and features the 5-step calibration block
• Measures the thickness of steel, cast iron, aluminum, acrylic resin, red copper, brass, zinc, quartz glass, polyethylene, PVC, grey cast iron, and nodular cast iron
• Easy-to-read backlit LCD display
• User-selectable units of measure (in/mm)
• Displays sound velocity at the touch of a button
• User-adjustable High/Low alarms
• Automatic material calibration
• Auto shut-off and low battery indicator

Specifications

• Display: Digital
• Measuring Mode: Ultrasound

Additional Specifications

• Accuracy: <10mm: ±0.1mm
• Measuring Range: 0.04 to 11.8" (1 to 300mm)
• Velocity Range: 1000 to 9999m/s (0.039 to 0.394in/µs)
• Probe Length: 3' (91cm)
• Probe Diameter: 3' (91cm)
• Operating Temperature: 32 to 104°F (0 to 40°C)
• Operating Humidity Range: 20 to 80%
