IC854-Clamp-On Ground Resistance Tester

• Enables non-contact measurements of ground conductors without the need for auxiliary ground spikes
• Auto-ranging ground resistance and leakage current measurements
• 0.001Ω resolution for low resistance measurements
• 9999-count EBTN display
• Internal memory capable of storing up to 300 measurements, allowing for a user to set alarm thresholds
• Features a double molded conductor clamp for added protection
• User adjustable alarms
• Data hold function
• 1.26" (32mm) jaw size for large ground rods
• Low battery indicator and auto shut-off

Specifications

• Display Type: Digital

Additional Specifications

• Ground Resistance Ranges: 0.010 to 0.099Ω, 0.10 to 0.99Ω, 1.0 to 49.9Ω, 50.0 to 99.5Ω, 100 to 199Ω, 200 to 395Ω, 400 to 590Ω, 600 to 880Ω, 900 to 1200Ω
• Current Ranges: 0 to 9mA, 10 to 99mA, 100 to 299mA, 0.30 to 2.99A, 3 to 9.9A, 10 to 20A
• Sampling Time: 0.5 Seconds
• Power Supply: (4) AA Batteries
• Jaw Opening: (4) AA Batteries
• Overvoltage Category: Cat III 300 V
• Certification(s): CE, RoHS
• Operating Temperature: 32 to 131°F (0 to 55°C)
• Operating Humidity: 10 to 90%
