IC790-True RMS Clamp Meter with Flexible Current Probe & ISO Certificate

• Measures AC/DC current and voltage, resistance, capacitance, frequency, duty cycle, and contact temperature
• Comes equipped with an 18" flexible current probe that can expand AC current measurements up to 3000A
• 6000-Count backlit LCD display and analog bargraph plus built-in non-contact voltage detector with LED indicator
• Ergonomic design fits in your hand and can be used while wearing protective gloves and only weighs 15.8oz (447g)
• Built-in LED flashlight, durable double molded plastic housing, and low battery and over range indicators
• True RMS voltage and current for accurate measurements
• Low pass filter and low impedance (LoZ) modes
• Min/Max, display hold and relative mode
• Diode test and continuity check functions
• Cat. III 1000V, Cat. IV 600V safety rating
• Operating temperature of 32 to 122°F (0 to 50°C) and a storage temperature of 14 to 140°F (-10 to 60°C)
• Runs on 3 x AAA batteries and features an autoshut-off after 15 minutes
• CE and ETL product certifications
• AC/DC voltage range: 6, 60, 600, 1000V (AC), 600mV, 6, 60, 600, 1000V (DC)
• AC/DC voltage accuracy: ±(1.0% rdg. +8 dgt.) (AC), ±(0.5% rdg. +5 dgt.) (DC)
• AC/DC voltage resolution: 0.1mV, 0.001V, 0.01V, 0.1V, 1V
• Includes: REED 1000A True RMS digital clamp meter (R5055), REED 3000A Flexible 18" current probe (R5065), ISO Certificate with full data and uncertainties

Specifications

• Voltage Readings: AC/DC
• Current Readings: AC/DC

Additional Specifications

• AC/DC Current Range: 60, 600, 1000A
• AC/DC Current Accuracy: AC/DC: ±(2% rdg. +5 dgt.)
• AC/DC Current Resolution: 0.01, 0.1, 1A
• Resistance Range: 600Ω, 6, 60, 600kΩ, 6, 60MΩ
• Resistance Accuracy: 600Ω, 6, 60, 600kΩ, 6, 60MΩ
• Capacitance Range: 60, 600.0nF, 6, 60, 600µF, 6, 60mF
• Capacitance Accuracy: ±(4.0% rdg. +5 dgt.)
• Capacitance Resolution: 0.01nF, 0.1nF, 0.001μF, 0.01μF, 0.1μF, 0.001mF, 0.01mF
• Dimensions: 10.7" x 3.2" x 1.7" (272 x 81 x 43.5mm)
