IC768-True RMS Digital Clamp Meter

• Measures AC/DC current/voltage, resistance, capacitance, frequency, duty cycle, and contact temperature
• Features a 6000 count backlit LCD display with a 31-segment analog bargraph
• Durable double molded plastic housing
• Keeps track of min/max readings and includes low pass filter and Low impedance (LoZ) mode
• Ergonomic design fits in user's hand and can be used while wearing protective gloves
• Built-in LED flashlight
• Low battery and over range indicators
• Built-in non-contact voltage detector with LED indicator
• True RMS voltage and current for accurate measurements
• Diode test and continuity check functions
• Certified to CE and ETL
• Includes: (1) AC/DC True RMS clamp meter, (1) Type K thermocouple, (1) Set of test leads, (1) Carrying case, (3) AAA Batteries

Specifications

• Voltage Readings: AC/DC
• Current Readings: AC/DC

Additional Specifications

• AC/DC Current Range: 60A, 600A, 1000A
• AC/DC Voltage Range: AC - 6V, 60V, 600V, 1000V, DC - 600mV, 6V, 60V, 600V, 1000V
• Resistance Range: 600Ω, 6, 60, 600kΩ, 6, 60MΩ
• Capacitance Range: 60, 600.0nF, 6, 60, 600μF, 6, 60mF
• Frequency Range: 60, 600.0nF, 6, 60, 600μF, 6, 60mF
• Low Pass Filter (LPF) AC Voltage Range: 600, 1000V
• Low Impedance (LoZ) AC Voltage Range: 600, 1000 V
• Temperature Range: -40 to 1832°F (-40 to 1000°C)
• Jaw Opening: 1.7" (42mm), up to 1500 MCM
