IC559-Non-Contact Phase Rotation Tester with ISO Certificate

• Non-contact voltage sensing alligator clips promote safety
• Colour-coded leads (red, black, blue) meet IEC 60446 standards
• LEDs indicate phase orientation (clockwise or counter-clockwise) and whether each phase is live
• Adjustable LED brightness allows for measurement in sunlight and lowly lit environments
• Beeper sounds intermittently when detecting correct phase and continuously for a reversed phase
• Durable housing with magnets frees hands and allows for easy measurement
• Low battery indicator
• Includes: (1) Rotation tester, (1) ISO Certificate with full Data and Uncertainties, (3) Colour-coded cables with alligator clips, (1) 9V Battery, (1) Soft carrying case

Specifications

• Display Type: Digital
• No. of Phases: 3

Additional Specifications

• Voltage Detection Method: Static Induction
• Voltage Range: 75 - 1000 VAC
• Frequency: 45 - 65 Hz
• Indicators: Audible (Buzzer) / Visual (LED)
• Power Supply: Audible (Buzzer) / Visual (LED)
• Overvoltage Category: CAT. III 1000V, CAT. IV 600V
• Cable Length: 31.5" (800 mm)
• Alligator Clip Jaw Opening: 1.18" (30 mm)
