IB751-Pipe Video Inspection System

• Cost effective portable inspection camera
• Designed to deliver quality video inspection in a wide range of applications including: sewers, building ducts/piping, wells, and power plants
• System includes camera head, cable reel with 65.6' (20 m) cable, battery pack and DVR
• Camera head contains 12 white LED lights, a flexible spring coiled joint to navigate corners, a scratch-resistant sapphire lens cover and a stainless steel housing that allows the camera to withstand various hits
• High resolution CCD chip is designed to capture bright, crisp, colour video of the inspection area
• Cable reel is mounted and rotatable in the case, therefore the fibreglass rod cable can be pushed in and out without the need to hold the reel
• Sun visor is included to act as a sun shield for outdoor inspections

Specifications

• Display Size: 7"
• Camera Head: 23 mm (0.9")

Additional Specifications

• DVR Resolution: 800 x 480 RGB
• DVR Output: TV and Audio
• External Memory: Supports SD memory card up to 32GB
• Viewing Angle: 140°
• 140°
