IA854-LCR Meter

• Autoranging operation for AC impedance and DE resistance measurement
• Auto LCR smart check and measurement
• Series/Parallel modes
• Ls/Lp/Cp with D/Q/Ø/ESR parameters
• Support DCR mode 200 to 200MΩ
• High accuracy with 4 or 5 terminal Kelvin measurement
• Testing frequency is up to 10kHz and output frequency is up to 100kHz
• Dual display with backlight
• Data hold function
• Low battery indication with auto power off
• Dust and water proof to IP67

Specifications

• Hand Held/Bench Model: Hand Held

Additional Specifications

• Test Frequencies: 100/120/1k Hz 10k Hz 100k Hz
• Test Signal Level: 0.5V AC RMS typical
• Power Supply: 6 x 1.5V AA batteries
• Dimensions: 8-19/32 x 3-11/16" x 2-13/32"
• 8-19/32 x 3-11/16" x 2-13/32"
