IA811-Insulation Tester

• Features a variable range to allow any intermediate voltage from 10 V to 1000 V in 1 V steps, when testing specific test voltages that do not appear in the standard ranges is required
• Functions such as PI (Polarisation Index) and DAR (Dielectric Absorption Ratio), capacitance measurement and a greater range of test voltages increase the suitability for many applications
• Designed for electrical and industrial testing
• Stabilised insulation test voltage
• Test result storage of up to 1000 test results
• Live circuit detection and protection
• Over-moulded for increased protection
• IP54 weatherproof rating
• Battery life of approximately 3000 insulation tests with duty cycle of 5 sec ON /55 sec OFF @ 1000 V into 1 MΩ
• 60 second countdown timer
• Default set up to single polarity, configurable to dual polarity
• Meets Category IV 600V standards
• Included: (1) Insulation tester, (1) SP5 Remote switch probe, (1) Set of red/black silicone test leads with probes & clips, (1) Hard carrying case, (6) AA Alkaline batteries, (1) Information CD

Specifications

• Display Type: Analogue/Digital

Additional Specifications

• Nominal Test Voltages: 50 V, 100 V, 250 V, 500 V, 1000 V
• Insulation Accuracy: 50 Volts (10 GΩ ± 2% ± 2 digits ± 4.0% per GΩ), 100 Volts (20 GΩ ± 2% ± 2 digits ± 2.0% per GΩ), 250 Volts (50 GΩ ± 2% ± 2 digits ± 0.8% per GΩ), 500 Volts (100 GΩ ± 2% ± 2 digits ± 0.4% per GΩ), 1000 Volts (200 GΩ ± 2% ± 2 digits ± 0.2% per GΩ)
• Continuity Measurement: 0.01 Ω - 999 kΩ (0 - 1000 kΩ on Analogue Scale)
• Voltage Range (AC): 10 mV - 600 V TRMS sinusoidal (15 - 400 Hz)
• Voltage Range (DC): 10 mV - 600 V TRMS sinusoidal (15 - 400 Hz)
• Volt Range Accuracy: AC ( ±2% ±1 digit ) & DC ( ±2% ±2 digit )
• Capacitance Range: 1 nF - 10 μF
• Capacitance Accuracy: ± 5.0% ± 2 digits (0.1 nF - 1 nF unspecified)
• Operating Temperature Range: -10 - 55 °C
