IA190-Ground Resistance Testers

• Measures ground resistance from 0.025 Ω to 1550 Ω
• Measures ground leakage current form 0.2 mA to 35 A
• Induces test current into system without disturbing existing connections
• True RMS current measurement facility
• Automatic self calibration
• Auto ranging
• Auto power off (configurable)
• Configurable high and low alarms with audible indication
• Indication of high noise content that may affect readings
• On-board storage of test results
• Hold function
• Over current protected
• Accommodates conductors up to 1.37" (35 mm) in diameter
• RS232 interface
• Complete with heavy-duty carrying case, multi-value resistance calibration check loop, download cable and Download Manager driver
• Ground Resistance Tester

Specifications

• Display Type: Digital
